Smart Street Light
·Reserve 5G base station interface for 5G communication equipment
· Intelligent lighting, supports remote switch lights, dimming, timing, etc
·Built-in high-definition camera, users can remotely monitor the road picture through mobile phone or PC
·The light pole is equipped with WIFI hotspot equipment, and the surrounding users
can connect to the WIFI hotspot for Internet browsing
·Built-in broadcasting speakers, support remote audio transmission for remote intercom
·Built-in a variety of weather sensors for environmental monitoring
·Equipped with outdoor LED screen, support remote sending of information,
display real-time weather information, advertising information, etc
·With one-button alarm function, quickly report accident information and intelligent unlocking ·Smart unlock
·High-tech park ·Tourist scenic area ·Park plaza ·Commercial district
|
Light pole |
The pole height is 4~13 meters, material: high-quality steel Q235; process: hot dip galvanized inside and outside, surface polyester powder coating; protection level: IP65 |
|
LED lights |
Power: 40W~150W; working voltage: AC220V/50Hz; color temperature: white light 4000~5500K; protection level: IP67 |
|
Security camera |
2/4 million outdoor high-speed PTZ ball machine; support 1080p@60fps, 960p@60fos, 720p@60fos high frame rate output; support 360° horizontal rotation, vertical direction -15°-90°; lightning protection, anti-surge; water protection grade: IP66 |
|
Digital broadcasting |
Power: 20W~40W; protection level: IP65 |
|
One-button alarm |
Support RJ45 interface/UDP/TCP/RTP protocol; audio sampling: 8kHz~441kHz |
|
LED information display |
Outdoor display screen; size: 480*960/512*1024/640*1280mm (optional); pixel density: 128*256pix; brightness level: ≥5000cd/m; refresh rate: >1920Hz; RJ45 network interface; working voltage : AC220V/50Hz; water protection grade: IP65 |
|
Environmental monitoring |
PM2.5/PM10 particle range: 0.3~1.0/1.0~2.5/2.5-10um; measurement range: 0~999ug/m³; accuracy ±0.1ug Carbon dioxide; effective range: 3000-5000ppm, accuracy: ±(50ppm+5%Fs); resolution: 1ppm Noise: 30~110dB, ±3%Fs |
|
Weather monitoring |
Air temperature: -20℃~90℃; resolution: 0.1℃ Atmospheric pressure: measuring range 1~110kPa Light intensity: 0~200000Lux; resolution: 1Lux Wind speed: starting wind 0.4~0.8m/s, resolution 0.1m/s; wind direction: 360°, dynamic speed ≤0.5m/s Wind direction: range: 0-360°, accuracy: earth 3°, resolution: 1°, starting wind speed: ≤0.5m/s |
|
LED single lamp power saving control |
Single lamp monitoring: voltage AC0~500V, current AC0~80A, output control: AC200V/10A; voltage, current, power, power factor collection; dimming interface: DC0~10V; light-off failure alarm |
|
Charging pile |
AC charging AC220V/50Hz; power 7kW; pay by credit card or WeChat payment |
|
Network equipment |
5G micro base station, antenna: 64 antenna interface; channel width: 20/40/50/60/80/100MHz Wireless AP (WiFi): Coverage from 100 meters to 300 meters, transmission standard: 802.11a, 802., dual-band concurrent 2.4G, built-in firewall |
|
Mobile client |
Mobile APP |
|
Power cord accessories |
National standard rubber insulated cable three-core YZ3mm*2.5mm square power cord; 3P/63 circuit breaker, etc |
